Charging capacity

Up to 22KW

Input/Output power

400VAC±20%-50/60Hz-32A- 3phase
240VAC±20%-50/60Hz-48A- 1phase (optional)

RCD

RCMU(Type A+ DC 6mA)/ Type B RCBB(Optional)

Standby power

<3W

Measuring accuracy

1%

Energy Meter

MID certified

Load balancing

CT+Meter(Optional)

PEN Protection

Optional

OCPP

OCPP1.6 Json(OCPP2.0 optional)

Communication

Bluetooth/WIFI/Ethernet/4G(Optional)

User interface

LED / LCD(3.5″) / RFID(mifare iso& IEC 14443A)

Input Plug

NEMA 14-50(Optional)

Certificate/Compliance

CE/RCC/ROHS/REACH/IEC/EN 61851-1，IEC/EN61851-21-2, IEC/EN 62955, EN300328, EN 301489-1/-17,EN62479,UL 817, UL 991, UL 2231, UL 225, and UL 2594.

Charging Interface

Type 2 socket/ 5M Cable
SAE J1772 48A 5M Cable (optional)

Special Protection

Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection

Protection

IP65, IK10

Enclosure

Plastic PC940/ Galvanized steel

Front Panel

Temper glass

Installation

Wall-mount/Pole-mount

Cooling

Natural cooling

Operating temperature

-30˚C to +55˚C

Product Dimensions

410*230*265(L*W*H)mm

Product Weight

8kg

Package Dimension

480*340*290(L*W*H)mm

Gross Weight
