Charging capacity |
Up to 40KW |
|
Input/Output power |
400VAC±10%-50/60Hz- 3phase |
|
Power factor |
0.98 |
|
Efficiency |
>93% |
|
Measuring accuracy |
Level 0.5 |
|
Output voltage range |
CCS: 300~1000VDC |
|
Output current range |
0-53A*2 |
|
Communication |
Ethernet/WIFI/4G/OCPP 1.6 Json (OCPP 2.0 optional) |
|
User interface |
RFID card and APP |
|
Display |
LCD 7 inch Touch Screen |
|
Certificate/Compliance |
CE/RCC/ROHS/REACH/IEC/EN 61851-1，IEC/EN61851-21-2, IEC/EN 62955, EN300328, EN 301489-1/-17,EN62479. |
|
Energy Meter |
PTB certified |
|
RCD |
Type A or Type B(optional) |
|
Security design |
Over/under voltage protection, overload protection, current leakage protection, grounding protection,lightening surge protection |
|
DC Plugs |
CCS2/ CHAdeMO 5M Cable |
|
Application place |
Indoor / outdoor |
|
Installation method |
Wall mount, pedestal mount (optional) |
|
Sound noise |
<55DB in all directions |
|
Operating temperature |
-20°C to +50°C |
|
Product Dimensions |
660*465*330(L*W*H)mm |
|
Product Weight |
55kg |
|
Package Dimension |
870*555*505(L*W*H)mm |
|
Gross Weight |
60kg |
