Charging capacity |
Up to 7KW |
|
Input/Output power |
230VAC±20%-50/60Hz-32A- 1phase |
|
RCD |
RCMU(Type A+ DC 6mA)/ Type B RCBB(Optional) |
|
Standby power |
<3W |
|
Measuring accuracy |
1% |
|
Communication |
Bluetooth/WIFI(Optional) APP |
|
Load balancing |
CT+Meter(Optional) |
|
PEN Protection |
Optional |
|
User interface |
LED/LCD(3.5")/ RFID(mifare iso& IEC 14443A) |
|
Certificate/Compliance |
CE/RCC/ROHS/REACH/IEC/EN 61851-1，IEC/EN61851-21-2, IEC/EN 62955, EN300328, EN 301489-1/-17,EN62479 |
|
Charging Interface |
Type 2 Socket/ 5M Cable |
|
Special Protection |
Over current protection, Residual current protection, Ground protection, Surge |
|
Protection |
IP54, IK10 |
|
Enclosure |
Plastic PC940/ Galvanized steel |
|
Front Panel |
Temper glass |
|
Installation |
Wall-mount/Pole-mount |
|
Cooling |
Natural cooling |
|
Operating temperature |
-30℃ to +55℃ |
|
Product Dimensions |
320*230*100(L*W*H)mm |
|
Product Weight |
8kg |
|
Package Dimension |
480*340*290(L*W*H)MM |
|
Gross Weight |
9kg |
