Charging capacity
|
Up to 60KW
|
|
Input/Output power
|
400VAC±10%-50/60Hz- 3phase
|
|
Power factor
|
0.98
|
|
Efficiency
|
>95%
|
|
Measuring accuracy
|
Level 0.5
|
|
Output voltage range
|
CCS: 300~1000VDC
|
|
Output current range
|
0-180A
|
|
Communication
|
PLC (between charger & vehicle)
Ethernet/4G/Wifi/OCPP 1.6J(optional) |
|
User interface
|
LCD(3.5’’) / RFID Card and APP
|
|
Certificate/Compliance
|
EN/IEC 61851-1: 2019, EN/IEC 61851-23: 2014
|
|
Energy Meter
|
PTB certified
|
|
RCD
|
Type A or Type B(optional)
|
|
Special Protection
|
Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection
|
|
LCD screen
|
55”IPS 1920*1080 16:9 HDV 2500cd/m²
|
|
Application platform
|
Android 4.3 and above
|
|
Ad update
|
USB flash disk,SD card, wired network remote release
|
|
Protection
|
IP55(outdoor)
|
|
Special Protection
|
Topple & fall down protection
|
|
Cooling
|
Natural cooling
|
|
Operating temperature
|
-20℃ to +55℃
|
|
Product Dimensions
|
1900*916*280(L*W*H)
|
