Charging capacity

Up to 3.5KW

Input/Output power

230VAC±20%，50/60Hz，8A-10A-13A- 16A adjustable，1-phase

RCD

Type AC 30mA/ RCMU(Type A+DC6mA)(Optional)

Standby power

<2W

Measuring accuracy

1%

Certificate/Compliance

CE/IEC61851-1,IEC61851-22

Charging Interface

5M cable with SAE1772 Type1/IEC62196-2(Type2)(optional)

Power Cord Plug

Schuko/NEMA6-20P

Protection

IP65,IK10

Special Protection

Temperature sensor and plug a dapter

Cooling

Natural cooling

Operating temperature

-30℃to+55℃

Product Dimensions

210*88*50(L*W*H)mm

Product Weight

2.5kg

Package Dimension

350*320*60(L*W*H)mm

Gross Weight

3kg
