Charging capacity

Up to 7.5KW

Input/Output power

240VAC-50/60Hz-32A-1phase

RCD

RCMU(Type A+ DC 6mA)/ Type B RCBB(Optional)

Standby power

<3W

Measuring accuracy

1%

Energy Meter

MID certified

OCPP

OCPP1.6 Json(OCPP2.0 optional)

Communication

WIFI / Ethernet / 4G(Optional)

User  interface

LED / LCD(3.5’’) / RFID(mifare iso& IEC 14443A)

Input Plug

NEMA 14-50(Optional)

Certificate/Compliance

NEC 625, SAE J1772, UL 817, UL 991, UL 2231, UL 225, and UL 2594.

Charging Interface

SAE J1772 32A 5M cable

Special Protection

Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection

Protection

IP54, IK10

Enclosure

Plastic PC940/ Galvanized steel

Front Panel

Temper glass

Installation

Wall-mount/Pole-mount

Cooling

Natural cooling

Operating temperature

-30˚C to +55˚C

Product Dimensions

320*230*100(L*W*H)mm

Product Weight

8kg

Package Dimension

480*340*290(L*W*H)mm

Gross Weight

9kg
